| 型号 PART NO. | 极性POLARITY | 集电极耗散功率PCM | 集电极电流IC | 集电极基极击穿电压 BVCBO | 集电极发射极击穿电压BVCEO | 发射极击穿电压BVEBO | 放大倍数hFE | 集电极发射极饱和电压VCE(sat) | 频率Ft | 印字代码Marking Code | 封装Package | |||||
| Min | Max | Vce | Ic | IC | IB | |||||||||||
| mW | mA | V | V | V | V | mA | V | mA | mA | MHz | ||||||
| S9012-LQ | PNP | 300 | -500 | -40 | -25 | -5 | 120 | 200 | -1 | -50 | -0.6 | -500 | -50 | 150 | 2T1 | SOT-23 |
| S9012-HQ | PNP | 300 | -500 | -40 | -25 | -5 | 200 | 350 | -1 | -50 | -0.6 | -500 | -50 | 150 | 2T1 | SOT-23 |
| S9012-JQ | PNP | 300 | -500 | -40 | -25 | -5 | 350 | 400 | -1 | -50 | -0.6 | -500 | -50 | 150 | 2T1 | SOT-23 |
| S9013-LQ | NPN | 300 | 500 | 40 | 25 | 5 | 120 | 200 | 1 | 50 | 0.6 | 500 | 50 | 150 | J3 | SOT-23 |
| S9013-HQ | NPN | 300 | 500 | 40 | 25 | 5 | 200 | 350 | 1 | 50 | 0.6 | 500 | 50 | 150 | J3 | SOT-23 |
| S9013-JQ | NPN | 300 | 500 | 40 | 25 | 5 | 300 | 400 | 1 | 50 | 0.6 | 500 | 50 | 150 | J3 | SOT-23 |
| S9014-LQ | NPN | 200 | 100 | 50 | 45 | 5 | 200 | 450 | 5 | 1 | 0.3 | 100 | 5 | 150 | J6 | SOT-23 |
| S9014-HQ | NPN | 200 | 100 | 50 | 45 | 5 | 450 | 1000 | 5 | 1 | 0.3 | 100 | 5 | 150 | J6 | SOT-23 |
| S9015-LQ | PNP | 200 | -100 | -50 | -45 | -5 | 200 | 450 | -5 | -1 | -0.3 | -100 | -10 | 150 | M6 | SOT-23 |
| S9015-HQ | PNP | 200 | -100 | -50 | -45 | -5 | 450 | 1000 | -5 | -1 | -0.3 | -100 | -10 | 150 | M6 | SOT-23 |
| S8050-LQ | NPN | 300 | 500 | 40 | 25 | 5 | 120 | 200 | 1 | 50 | 0.6 | 500 | 50 | 150 | J3Y | SOT-23 |
| S8050-HQ | NPN | 300 | 500 | 40 | 25 | 5 | 200 | 350 | 1 | 50 | 0.6 | 500 | 50 | 150 | J3Y | SOT-23 |
| S8550-LQ | PNP | 300 | -500 | -40 | -25 | -5 | 120 | 200 | -1 | -50 | -0.6 | -500 | -50 | 150 | 2TY·L | SOT-23 |
| S8550-HQ | PNP | 300 | -500 | -40 | -25 | -5 | 200 | 350 | -1 | -50 | -0.6 | -500 | -50 | 150 | 2TY | SOT-23 |
| SS8050-LQ | NPN | 300 | 1500 | 40 | 25 | 5 | 120 | 200 | 1 | 100 | 0.5 | 800 | 80 | 100 | Y1·L | SOT-23 |
| SS8050-HQ | NPN | 300 | 1500 | 40 | 25 | 5 | 200 | 350 | 1 | 100 | 0.5 | 800 | 80 | 100 | Y1 | SOT-23 |
| SS8550-LQ | PNP | 300 | -1500 | -40 | -25 | -5 | 120 | 200 | -1 | -100 | -0.5 | -800 | -80 | 100 | Y2·L | SOT-23 |
| SS8550-HQ | PNP | 300 | -1500 | -40 | -25 | -5 | 200 | 350 | -1 | -100 | -0.5 | -800 | -80 | 100 | Y2 | SOT-23 |
| MMBT2222AQ | NPN | 300 | 600 | 75 | 40 | 6 | 100 | 300 | 10 | 150 | 1 | 500 | 50 | 300 | 1P | SOT-23 |
| MMBT2907AQ | PNP | 300 | -600 | -60 | -60 | -5 | 100 | 300 | -10 | -150 | -0.4 | -150 | -15 | 200 | 2F | SOT-23 |
| MMBT3904Q | NPN | 300 | 200 | 60 | 40 | 6 | 100 | 300 | 1 | 10 | 0.3 | 50 | 5 | - | 1AMY | SOT-23 |
| MMBT3906Q | PNP | 300 | -200 | -40 | -40 | -5 | 100 | 300 | -1 | -10 | -0.4 | -50 | -5 | - | 2AY | SOT-23 |
| MMBT4401Q | NPN | 300 | 600 | 60 | 40 | 6 | 100 | 300 | 1 | 150 | 0.4 | 150 | 15 | 250 | 2X | SOT-23 |
| MMBT4403Q | PNP | 300 | -600 | -40 | -40 | -5 | 100 | 300 | -2 | -150 | -0.4 | -150 | -15 | 200 | 2T | SOT-23 |
| MMBT5401Q | PNP | 300 | -600 | -180 | -160 | -6 | 100 | 300 | -5 | -10 | -0.5 | -50 | -5 | 100-300 | 2L | SOT-23 |
| MMBT5551Q | NPN | 300 | 600 | 180 | 160 | 6 | 100 | 300 | 5 | 10 | 0.2 | 50 | 5 | 100-300 | G1 | SOT-23 |
| MMBTA42Q | NPN | 350 | 500 | 300 | 300 | 5 | 40 | 300 | 10 | 10 | 0.5 | 20 | 2 | 50 | 1D | SOT-23 |
| MMBTA06Q | NPN | 300 | 500 | 80 | 80 | 4 | 100 | 400 | 1 | 10 | 0.25 | 100 | 10 | 100 | 1GM | SOT-23 |
| MMBTA56Q | PNP | 300 | -500 | -80 | -80 | -4 | 100 | 400 | -1 | -10 | -0.25 | -100 | -10 | 100 | 2GM | SOT-23 |
| MMBTA92Q | PNP | 300 | -300 | -300 | -300 | -5 | 100 | 200 | -10 | -10 | -0.5 | -20 | -2 | 50 | 2D | SOT-23 |
| BC807-16Q | PNP | 300 | -500 | -50 | -45 | -5 | 100 | 250 | -1 | -100 | -0.7 | -500 | -50 | 100 | 5A | SOT-23 |
| BC807-25Q | PNP | 300 | -500 | -50 | -45 | -5 | 160 | 400 | -1 | -100 | -0.7 | -500 | -50 | 100 | 5B | SOT-23 |
| BC807-40Q | PNP | 300 | -500 | -50 | -45 | -5 | 250 | 600 | -1 | -100 | -0.7 | -500 | -50 | 100 | 5C | SOT-23 |
| BC817-16Q | NPN | 300 | 500 | 50 | 45 | 5 | 100 | 250 | 1 | 100 | 0.7 | 500 | 50 | 100 | 6A | SOT-23 |
| BC817-25Q | NPN | 300 | 500 | 50 | 45 | 5 | 160 | 400 | 1 | 100 | 0.7 | 500 | 50 | 100 | 6B | SOT-23 |
| BC817-40Q | NPN | 300 | 500 | 50 | 45 | 5 | 250 | 600 | 1 | 100 | 0.7 | 500 | 50 | 100 | 6C | SOT-23 |
| BC846AQ | NPN | 300 | 100 | 80 | 65 | 6 | 110 | 220 | 5 | 2 | 0.5 | 100 | 5 | 150 | 1A | SOT-23 |
| BC846BQ | NPN | 300 | 100 | 80 | 65 | 6 | 200 | 450 | 5 | 2 | 0.5 | 100 | 5 | 150 | 1B | SOT-23 |
| BC847AQ | NPN | 300 | 100 | 50 | 45 | 6 | 110 | 220 | 5 | 2 | 0.5 | 100 | 5 | 150 | 1E | SOT-23 |
| BC847BQ | NPN | 300 | 100 | 50 | 45 | 6 | 200 | 450 | 5 | 2 | 0.5 | 100 | 5 | 150 | 1F | SOT-23 |
| BC847CQ | NPN | 300 | 100 | 50 | 45 | 6 | 420 | 800 | 5 | 2 | 0.5 | 100 | 5 | 150 | 1G | SOT-23 |
| BC848AQ | NPN | 300 | 100 | 30 | 30 | 6 | 110 | 220 | 5 | 2 | 0.5 | 100 | 5 | 150 | 1J | SOT-23 |
| BC848BQ | NPN | 300 | 100 | 30 | 30 | 6 | 200 | 450 | 5 | 2 | 0.5 | 100 | 5 | 150 | 1K | SOT-23 |
| BC848CQ | NPN | 300 | 100 | 30 | 30 | 6 | 420 | 800 | 5 | 2 | 0.5 | 100 | 5 | 150 | 1L | SOT-23 |
| BC856AQ | PNP | 300 | -100 | -80 | -65 | -5 | 125 | 250 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3A | SOT-23 |
| BC856BQ | PNP | 300 | -100 | -80 | -65 | -5 | 220 | 475 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3B | SOT-23 |
| BC857AQ | PNP | 300 | -100 | -50 | -45 | -5 | 125 | 250 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3E | SOT-23 |
| BC857BQ | PNP | 300 | -100 | -50 | -45 | -5 | 220 | 475 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3F | SOT-23 |
| BC857CQ | PNP | 300 | -100 | -50 | -45 | -5 | 420 | 800 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3G | SOT-23 |
| BC858AQ | PNP | 300 | -100 | -30 | -30 | -5 | 125 | 250 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3J | SOT-23 |
| BC858BQ | PNP | 300 | -100 | -30 | -30 | -5 | 220 | 475 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3K | SOT-23 |
| BC858CQ | PNP | 300 | -100 | -30 | -30 | -5 | 420 | 800 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3L | SOT-23 |
| 2SD1782-RQ | NPN | 200 | 500 | 80 | 80 | 5 | 180 | 390 | 3 | 100 | 0.5 | 500 | 50 | Typ：180 | AJR | SOT-23 |
| 2SB1198-RQ | PNP | 200 | -500 | -80 | -80 | -5 | 180 | 390 | -3 | -100 | -0.5 | -500 | -50 | Typ：180 | AKR | SOT-23 |
| BC846AWQ | NPN | 200 | 100 | 80 | 65 | 6 | 110 | 220 | 5 | 2 | 0.5 | 100 | 5 | 100 | 1A | SOT-323 |
| BC846BWQ | NPN | 200 | 100 | 80 | 65 | 6 | 200 | 450 | 5 | 2 | 0.5 | 100 | 5 | 100 | 1B | SOT-323 |
| BC847AWQ | NPN | 200 | 100 | 50 | 45 | 6 | 110 | 220 | 5 | 2 | 0.5 | 100 | 5 | 100 | 1E | SOT-323 |
| BC847BWQ | NPN | 200 | 100 | 50 | 45 | 6 | 200 | 450 | 5 | 2 | 0.5 | 100 | 5 | 100 | 1F | SOT-323 |
| BC847CWQ | NPN | 200 | 100 | 50 | 45 | 6 | 420 | 800 | 5 | 2 | 0.5 | 100 | 5 | 100 | 1G | SOT-323 |
| BC848AWQ | NPN | 200 | 100 | 30 | 30 | 6 | 110 | 220 | 5 | 2 | 0.5 | 100 | 5 | 100 | 1J | SOT-323 |
| BC848BWQ | NPN | 200 | 100 | 30 | 30 | 6 | 200 | 450 | 5 | 2 | 0.5 | 100 | 5 | 100 | 1K | SOT-323 |
| BC848CWQ | NPN | 200 | 100 | 30 | 30 | 6 | 420 | 800 | 5 | 2 | 0.5 | 100 | 5 | 100 | 1L | SOT-323 |
| BC856AWQ | PNP | 200 | -100 | -80 | -65 | -5 | 125 | 250 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3A | SOT-323 |
| BC856BWQ | PNP | 200 | -100 | -80 | -65 | -5 | 220 | 475 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3B | SOT-323 |
| BC857AWQ | PNP | 200 | -100 | -50 | -45 | -5 | 125 | 250 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3E | SOT-323 |
| BC857BWQ | PNP | 200 | -100 | -50 | -45 | -5 | 220 | 475 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3F | SOT-323 |
| BC857CWQ | PNP | 200 | -100 | -50 | -45 | -5 | 420 | 800 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3G | SOT-323 |
| BC858AWQ | PNP | 200 | -100 | -30 | -30 | -5 | 125 | 250 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3J | SOT-323 |
| BC858BWQ | PNP | 200 | -100 | -30 | -30 | -5 | 220 | 475 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3K | SOT-323 |
| BC858CWQ | PNP | 200 | -100 | -30 | -30 | -5 | 420 | 800 | -5 | -2 | -0.65 | -100 | -5 | 100 | 3L | SOT-323 |
| BC817-16WQ | NPN | 200 | 500 | 50 | 45 | 5 | 100 | 250 | 1 | 100 | 0.7 | 500 | 50 | 100 | 6A | SOT-323 |
| BC817-25WQ | NPN | 200 | 500 | 50 | 45 | 5 | 160 | 400 | 1 | 100 | 0.7 | 500 | 50 | 100 | 6B | SOT-323 |
| BC817-40WQ | NPN | 200 | 500 | 50 | 45 | 5 | 250 | 600 | 1 | 100 | 0.7 | 500 | 50 | 100 | 6C | SOT-323 |
| MMST2222AQ | NPN | 200 | 600 | 75 | 40 | 6 | 100 | 300 | 10 | 150 | 1 | 500 | 50 | 300 | K3P | SOT-323 |
| MMST2907AQ | PNP | 200 | -600 | -60 | -60 | -5 | 100 | 300 | -10 | -150 | -0.4 | -150 | -15 | 200 | K3F | SOT-323 |
| MMST3904Q | NPN | 200 | 200 | 60 | 40 | 6 | 100 | 300 | 1 | 10 | 0.3 | 50 | 5 | - | K2N | SOT-323 |
| MMST3906Q | PNP | 200 | -200 | -40 | -40 | -5 | 100 | 300 | -1 | -10 | -0.4 | -50 | -5 | - | K5N | SOT-323 |
| MMST4401Q | NPN | 200 | 600 | 60 | 40 | 6 | 100 | 300 | 1 | 150 | 0.4 | 150 | 15 | 250 | K3X | SOT-323 |
| MMST4403Q | PNP | 200 | -600 | -40 | -40 | -5 | 100 | 300 | -2 | -150 | -0.4 | -150 | -15 | 200 | K3T | SOT-323 |
| BC847BSQ | NPN | 200 | 100 | 50 | 45 | 6 | 200 | 450 | 5 | 2 | 0.65 | 100 | 5 | 100 | 1C | SOT-363 |
| BC847PNQ | NPN+PNP | 200 | 100 | 50 | 45 | 6 | 200 | 450 | 5 | 2 | 0.65 | 100 | 5 | 100 | 7P | SOT-363 |
| BC857BSQ | PNP | 200 | -100 | -50 | -45 | -6 | 220 | 475 | 5 | 2 | -0.65 | -100 | -5 | 100 | 3F | SOT-363 |
| MMDT3904Q | NPN | 200 | 200 | 60 | 40 | 6 | 100 | 300 | 1 | 10 | 0.3 | 50 | 5 | - | K6N | SOT-363 |
| MMDT3906Q | PNP | 200 | -200 | -40 | -40 | -5 | 100 | 300 | -1 | -10 | -0.4 | -50 | -5 | - | K3N | SOT-363 |
| MMDT3946Q | NPN+PNP | 200 | 200 | 60 | 40 | 6 | 100 | 300 | 1 | 10 | 0.3 | 50 | 5 | - | K46 | SOT-363 |
| MMDT5551Q | NPN | 200 | 600 | 180 | 160 | 6 | 100 | 300 | 5 | 10 | 0.2 | 50 | 5 | 100 | K4N | SOT-363 |
