| 型号 PARTNO. | 最大反向峰值电压 Max.Reverse Voltage | 最大正向电流Max.Aver. Rect.Current | Maximum reverse recovery time | 最大正向浪涌电流 Peak Fwd. Surge Current | 最大正向压降Max.Fwd.Voltage @25℃&Rated lo | 最大反向漏电流 Maximum Reverse Current@Rated VRM&Tc | 典型热阻 Typical Thermal Resistance | 结电容 Typical junction capacitance | 工作结温Operation Temp.Range | 封装 Package | ||
| VRM (V) | lo(A) | TRR(ns) | IFSM(A) | Rated lo(A) | VF(V) | @25℃IR(uA) | @125℃IR(uA) | RθJA(℃/W) | CJ（PF) | Tj（℃） | ||
| E1AQ | 50 | 1 | 35 | 30 | 1 | 1.0 | 5 | 100 | 85 | 12 | -55～+150 | SOD-123FL |
| E1BQ | 100 | 1 | 35 | 30 | 1 | 1.0 | 5 | 100 | 85 | 12 | -55～+150 | SOD-123FL |
| E1DQ | 200 | 1 | 35 | 30 | 1 | 1.0 | 5 | 100 | 85 | 12 | -55～+150 | SOD-123FL |
| E1FQ | 300 | 1 | 35 | 30 | 1 | 1.3 | 5 | 100 | 85 | 20 | -55～+150 | SOD-123FL |
| E1GQ | 400 | 1 | 35 | 30 | 1 | 1.3 | 5 | 100 | 85 | 20 | -55～+150 | SOD-123FL |
| E1JQ | 600 | 1 | 35 | 30 | 1 | 1.7 | 5 | 100 | 85 | 20 | -55～+150 | SOD-123FL |
| ES1AQ | 50 | 1 | 35 | 30 | 1 | 0.95 | 5 | 100 | 85 | 12 | -55～+150 | SMA |
| ES1BQ | 100 | 1 | 35 | 30 | 1 | 0.95 | 5 | 100 | 85 | 12 | -55～+150 | SMA |
| ES1CQ | 150 | 1 | 35 | 30 | 1 | 0.95 | 5 | 100 | 85 | 12 | -55～+150 | SMA |
| ES1DQ | 200 | 1 | 35 | 30 | 1 | 0.95 | 5 | 100 | 85 | 12 | -55～+150 | SMA |
| ES1FQ | 300 | 1 | 35 | 30 | 1 | 1.3 | 5 | 100 | 85 | 12 | -55～+150 | SMA |
| ES1GQ | 400 | 1 | 35 | 30 | 1 | 1.3 | 5 | 100 | 85 | 12 | -55～+150 | SMA |
| ES1HQ | 500 | 1 | 35 | 30 | 1 | 1.7 | 5 | 100 | 85 | 12 | -55～+150 | SMA |
| ES1JQ | 600 | 1 | 35 | 30 | 1 | 1.7 | 5 | 100 | 85 | 12 | -55～+150 | SMA |
| ES2AAQ | 50 | 2 | 35 | 50 | 2 | 0.95 | 5 | 100 | 85 | 30 | -55～+150 | SMA |
| ES2BAQ | 100 | 2 | 35 | 50 | 2 | 0.95 | 5 | 100 | 85 | 30 | -55～+150 | SMA |
| ES2CAQ | 150 | 2 | 35 | 50 | 2 | 0.95 | 5 | 100 | 85 | 30 | -55～+150 | SMA |
| ES2DAQ | 200 | 2 | 35 | 50 | 2 | 0.95 | 5 | 100 | 85 | 30 | -55～+150 | SMA |
| ES2FAQ | 300 | 2 | 35 | 50 | 2 | 1.3 | 5 | 100 | 85 | 25 | -55～+150 | SMA |
| ES2GAQ | 400 | 2 | 35 | 50 | 2 | 1.3 | 5 | 100 | 85 | 25 | -55～+150 | SMA |
| ES2HAQ | 500 | 2 | 35 | 50 | 2 | 1.7 | 5 | 100 | 85 | 20 | -55～+150 | SMA |
| ES2JAQ | 600 | 2 | 35 | 50 | 2 | 1.7 | 5 | 100 | 85 | 20 | -55～+150 | SMA |
| ES2AQ | 50 | 2 | 35 | 50 | 2 | 0.95 | 5 | 100 | 75 | 30 | -55～+150 | SMB |
| ES2BQ | 100 | 2 | 35 | 50 | 2 | 0.95 | 5 | 100 | 75 | 30 | -55～+150 | SMB |
| ES2CQ | 150 | 2 | 35 | 50 | 2 | 0.95 | 5 | 100 | 75 | 30 | -55～+150 | SMB |
| ES2DQ | 200 | 2 | 35 | 50 | 2 | 0.95 | 5 | 100 | 75 | 30 | -55～+150 | SMB |
| ES2FQ | 300 | 2 | 35 | 50 | 2 | 1.3 | 5 | 100 | 75 | 25 | -55～+150 | SMB |
| ES2GQ | 400 | 2 | 35 | 50 | 2 | 1.3 | 5 | 100 | 75 | 25 | -55～+150 | SMB |
| ES2HQ | 500 | 2 | 35 | 50 | 2 | 1.7 | 5 | 100 | 75 | 20 | -55～+150 | SMB |
| ES2JQ | 600 | 2 | 35 | 50 | 2 | 1.7 | 5 | 100 | 75 | 20 | -55～+150 | SMB |
| ES3ABQ | 50 | 3 | 35 | 100 | 3 | 0.95 | 5 | 100 | 65 | 60 | -55～+150 | SMB |
| ES3BBQ | 100 | 3 | 35 | 100 | 3 | 0.95 | 5 | 100 | 65 | 60 | -55～+150 | SMB |
| ES3CBQ | 150 | 3 | 35 | 100 | 3 | 0.95 | 5 | 100 | 65 | 60 | -55～+150 | SMB |
| ES3DBQ | 200 | 3 | 35 | 100 | 3 | 0.95 | 5 | 100 | 65 | 60 | -55～+150 | SMB |
| ES3FBQ | 300 | 3 | 35 | 100 | 3 | 1.3 | 5 | 100 | 65 | 60 | -55～+150 | SMB |
| ES3GBQ | 400 | 3 | 35 | 100 | 3 | 1.3 | 5 | 100 | 65 | 60 | -55～+150 | SMB |
| ES3HBQ | 500 | 3 | 35 | 100 | 3 | 1.7 | 5 | 100 | 65 | 60 | -55～+150 | SMB |
| ES3JBQ | 600 | 3 | 35 | 100 | 3 | 1.7 | 5 | 100 | 65 | 60 | -55～+150 | SMB |
| ES3AQ | 50 | 3 | 35 | 100 | 3 | 0.95 | 5 | 100 | 75 | 60 | -55～+150 | SMC |
| ES3BQ | 100 | 3 | 35 | 100 | 3 | 0.95 | 5 | 100 | 75 | 60 | -55～+150 | SMC |
| ES3CQ | 150 | 3 | 35 | 100 | 3 | 0.95 | 5 | 100 | 75 | 60 | -55～+150 | SMC |
| ES3DQ | 200 | 3 | 35 | 100 | 3 | 0.95 | 5 | 100 | 75 | 60 | -55～+150 | SMC |
| ES3FQ | 300 | 3 | 35 | 100 | 3 | 1.3 | 5 | 100 | 75 | 60 | -55～+150 | SMC |
| ES3GQ | 400 | 3 | 35 | 100 | 3 | 1.3 | 5 | 100 | 75 | 60 | -55～+150 | SMC |
| ES3HQ | 500 | 3 | 35 | 100 | 3 | 1.7 | 5 | 100 | 75 | 60 | -55～+150 | SMC |
| ES3JQ | 600 | 3 | 35 | 100 | 3 | 1.7 | 5 | 100 | 75 | 60 | -55～+150 | SMC |
