800V MOSFET选型手册

800V MOSFET选型手册

P/N	Cfg.	VDS(V)	VGS(V)	ID(A)	Vth_typ(V)	Ron(Ω)	Package
OSG80R300FF	N	800	30	15	3.4	0.3	TO-220F
OSG80R250FF	N	800	30	17	3.4	0.25	TO-220F
OSG80R900FF	N	800	30	5	3.4	0.9	TO-220F
OSG80R380FF	N	800	30	11	3.4	0.38	TO-220F
OSG80R650FF	N	800	30	8	3	0.65	TO-220F
OSG80R1K4FF	N	800	30	4	3	1.4	TO-220F
OSG80R650IF	N	800	30	8	3	0.65	TO-262
OSG80R900DF	N	800	30	5	3.4	0.9	TO-252
OSG80R650DF	N	800	30	8	3	0.65	TO-252
OSG80R1K4DF	N	800	30	4	3	1.4	TO-252
OSG80R069HZF	N	800	30	53	3.8	0.069	TO-247
OSG80R380HF	N	800	30	11	3.4	0.38	TO-247
OSG80R250HF	N	800	30	17	3.4	0.25	TO-247
OSG80R069HF	N	800	30	53	3	0.069	TO-247
OSG80R650AF	N	800	30	8	3	0.65	TO-251
OSG80R1K4AF	N	800	30	4	3	1.4	TO-251
OSG80R380KF	N	800	30	11	3.4	0.38	TO-263
OSG80R300KF	N	800	30	15	3.4	0.3	TO-263
OSG80R250KF	N	800	30	17	3.4	0.25	TO-263
OSG80R380PF	N	800	30	11	3.4	0.38	TO-220
OSG80R250PF	N	800	30	17	3.4	0.25	TO-220
OSG80R650PF	N	800	30	8	3	0.65	TO-220
OSG80R1K4PF	N	800	30	4	3	1.4	TO-220
OSG80R300JF	N	800	30	15	3.4	0.3	PDFN8*8
